Discover the new SIC MARKING LASER STATION FOR MARKING METALLIC TAGS with automatic label feeding
The laser TagMark is a fully automated laser marking station that will allow you to simultaneously manage the marking of your plates, on a single, safe, and synchronized work station with your own data.
✅ Laser marking head 20W Class 1 – Available in various power capacities
✅ SIC FACTORY AUTOMATION software included
✅ 1 or 2 charging route(s) – when dealing with 2 different tag sizes
✅ Tag container – Ordered stacking in option
✅ Steel construction chassis
Powerful Laser Source and Control Unit
TAGMARK LASER is available in standard or specific mode, as a stand-alone station or integrated to the production line. In standard, TAGMARK LASER is equipped with a laser machine i104 EASY with 20W fiber laser source.
TECHNOLOGY
- Pulsed fiber laser (variable frequency)
- Power consumption 750W
- Wavelength 1 064 NM
- Digital axis control (linear and rotary)
- Ultra compact : 4U height (177 mm)
PERFORMANCE
- Long component life expectancy ≥ 100 000 h
- Self-diagnostic function
- Air cooled only
- 2-year warranty (optional 5-year warranty)
SIC FACTORY AUTOMATION: an intuitive software
The SFA software from SIC Marking offers 3 user profiles, predefined cycles and the possibility to customize your own marking cycle.
DATA IMPORT – quick and simple
- File selection and data entry with a 1D or 2D barcode reader
- Import of marking data: references, variables, quantity of tags
- Database formats: csv, xlsx or xls
MARKING MASK – live preview
Instant display of the part marking on the screen
3 USER PROFILES – adaptability
- Operator: standard launch of a predefined marking cycle
- Advanced User: possibility to modify the marking criteria of a predefined cycle
- Supervisor: customization of advanced settings
